6kVA UPS StepDown Isolation Tr

Tripp Lite EZ-series SU6000RT4UHV 6000VA / 6kVA / 5400 watt on-line, double-conversion UPS system offers complete power protection for critical server, network and telecommunications equipment in a single 4U rack/tower compatible housing. Full-time active power conditioning provides clean, continuous dual-conversion AC output free of voltage fluctuations, power interruptions and line noise. Fault-tolerant auto-bypass prevents unexpected service interruptions during UPS overload or internal fault conditions. Detachable back panel PDU with manual bypass switch supports hot-swappable whole UPS replacement with no interruption to connected equipment. Single all-in-one rack / tower housing installs in only 4 rack spaces (4U) with a maximum installed depth of only 20.7 in. / 52.6cm. Maintains full-time sine wave output within 2% of selectable 200/208/220/230/240V nominal during brownouts as low 100V and overvoltages as high as 300V. Expandable runtime is supported with optional BP192V12-3U external battery packs. Battery independent restart ensures automatic UPS power-up without user interaction after lengthy power outages, even when Tripp Lite’s SU6000XFMRT2U step-down, isolation transformer converts 208 or 240V input from any generator, utility or UPS high voltage source to 120V low voltage output. 208 or 240V 30A input connection supported via hardware or included L6-30P input plug. 8 5-15/20R and 4 5-15R output receptacles accommodate 5-15P and 5-20P equipment plugs. Built-in L6-30R outlet supports one high voltage L6-30P plug. Supports 2U rackmount installation in 4 post racks with included brackets. Supports 2 post rackmount installation with optional 2POSTRMKITWM. Supports upright tower installation with 2-9USTAND. Key Features Step-down/isolation transformer converts high voltage 208 or 240V input from generator, utility or UPS to low voltage 120V output 6kVA / 6,000 watt power handling capacity 12 built-in NEMA 5-15/20R output receptacles accept common 5-15P and 5-20P equipment plugs; built-in L6-30R outlet supports one high voltage L6-30P plug Included mounting accessories support 2U installation in 4 post rack enclosures with a max depth requirement of only 27.25 inches Optional 2POSTRMKITHD enables 2 post relay-rack installation Optional 2-9USTAND accessory enables upright tower installation Typical Applications Ideal means of converting 208 or 240V power to 120V for a variety of IT, generator, facilities and UPS applications Adds 120V output to any 208V high voltage UPS with L6-30R or hardwire output connection Package Includes SU6000XFMRT2U step-down, isolation transformer 4 post rackmount accessories Owner’s manual with warranty information
