Mainpine Intelligent PCI-Express Fax Board

The IQ Express™ intelligent fax board provides customers with the speed, reliability and performance of enterprise-class fax hardware at an exceptional price-to-performace guarantee.

In an ultra-small low profile design, these 1, 2, 4 and 8-line PCI-Express analog fax boards are ideal for space constrained environments.

Speed. Performance. Reliability

The IQ Express™ supports the most advanced fax standards in the industry. The V.34 fax standard allows the board to fax at speeds up to 33600 bps. In actual use this commonly doubles fax throughput per port over V.17 (14400 bps). Error Correction Mode (ECM) allows the fax to intelligently cope with many types of occasional line problems and interference to deliver perfect image quality. SSL Fax harnesses internet speeds within traditional fax operations, making fax lightening fast.

These features are delivered by the advanced power of the IQ Express™ and IQFSP software. While other intelligent fax boards share a Controller (CPU) and Digital Signal Processor (DSP) between multiple ports, each port of the IQ Express™ has a dedicated CPU and DSP. This innovative design provides superior levels of speed, performance and reliability. and reliability.

Innovative Design for Space Constrained Environments

The IQ Express™ is the only low-profile short-format intelligent fax board in the industry. The IQ Express™ fax board ships with a standard-profile bracket attached; a low profile bracket is included in the package at no extra cost. This allows the IQ Express™ to be installed in today’s new 1U racks and slimline desktop systems.

Delivering more board features in less space, the IQ Express is only 6.6 inches in length and requires 50% less space than other intelligent fax board options.

• Super High-Speed Fax: Supports up to V.34 (33600 BPS) fax speed
• Error Correction Mode (ECM): Helps faxes negotiate through many kinds of problematic line conditions and interference
• Dedicated Processing Power Per Port: Dedicated CPU & DSP per port
• True Internet Fax Support – SSL Fax: Combined with Mainpine’s IQFSP software, the IQ Express supports SSL Fax, delivering fax at the speed of the internet.
• Wide Range of Applications Supported: Supports Fax Class 1, 1.0, and Microsoft Fax API for compatibility with a wide range of applications
• Supports All PCI-Express Expansion Slots: PCI-Express 2.5Gbps Single Lane (x1) Link supports all x1, x4, x8 and x16 PCI-Express slots
• Full Scalability: Unlimited number of 1, 2, 4 or 8 line boards can be placed in a single server
• Microsoft™ Fax Compatible: Mainpine Fax Service Provider (IQFSP) software adds high-speed fax, SSL Fax, and ECM to Microsoft Fax
• Environmentally Friendly Product: RoHS/WEEE certified device that exceeds worldwide environmental standards
• Peace of Mind: 30-day satisfaction guarantee, 5-year hardware warranty and free tech support
